Canon EOS 650D wird heute vorgestellt

Wir werden im laufe des Tages die weiteren Infos an dieser Stelle nachreichen, jedoch geistern schon seit gestern einige Infos durchs Netz, die bereits als gesichert gelten. Der 18 MP-APS-C-Sensor scheint geblieben, also nicht neu zu sein. Kurz zusammengefasst die guten Neuigkeiten im Videobereich: Zebra, h.264-MOV-Aufzeichnung mit variabler Bitrate (ca. 5,5 MB/s), 1080p30/25/24 sowie 720p50/60, SDHC-Slot ist USH-1 kompatibel, Touchscreen.

Die schlechten Neuigkeiten sind (bisher): Kein Kopfhöreranschluss, keine All-I-Kompression.

Das große Fragezeichen ist dagegen noch offen: Moires/Aliasing-Verhalten, aber wir denken dass sich Canon dazu in kürze äußern wird.

Bis dahin hier schon mal die Feature-Liste von Canon Rumors:

Canon EOS Rebel T4i Specs

• The form of digital single-lens reflex, AF / AE camera (flash included)
• Recording media SD Memory Card, SDHC Memory Card, SDXC memory card
• * UHS-I compliant
• Image sensor size 22.3 x 14.9 mm approx.
• Canon EF lenses, the lens (EF-S Lens) Crop Faktor

1,6
• Lens Mount Canon EF mount
• Image Sensor
• Type CMOS sensors
• Approximately 18 million pixels Effective Pixels
• Aspect Ratio 3:02
• Dust features: automatic, manual, dust delete data attached

Recording System

• Recording Format

Design rule for Camera File system (DCF) 2.0
• Image format JPEG, RAW (14bit Canon proprietary method)
• Can simultaneously record RAW + JPEG Large
• Number of recorded pixels L (Large): Approximately 17.90 megapixels (5184 x 3456)
• M (Medium): approx. 8.00-megapixel (3456 x 2304)
• S1 (Small 1): Approx 4.50 megapixels (2592 x 1728)
• S2 (Small 2): Approx 2.50 megapixels (1920 x 1280)
• S3 (Small 3): Approximately 350,000 pixels (720 x 480)
• RAW: Approximately 17.90 megapixels (5184 x 3456)

Shooting image processing

• Picture Style Auto, Standard, Portrait, Landscape, Neutral, Faithful, Monochrome, User Def. 1-3
• Select expression functions: shooting environment by choosing, depending on lighting and shooting scene
• White Balance Auto, Preset (Daylight, Shade, Cloudy, Tungsten light, White fluorescent light, Flash),

Custom

• White balance correction and white balance bracketing features
• * Flash color temperature information for communication
• Prolonged exposure and ISO noise reduction can be applied to shooting with high sensitivity
• Auto Lighting Optimizer automatically calibrate the brightness of the image
• Highlight tone Priority
• Ambient light correction lens aberration correction, chromatic aberration correction

Viewfinder

• Type Eye-level pentaprism
• Coverage Vertical / Horizontal approx 95% (approximately eyepoint 19mm)
• Magnification approximately 0.85x (with 50mm lens at infinity -1 m-1)
• Eyepoint approximately 19 mm (-1 m-1 from eyepiece lens center at)
• Built-in diopter adjustment of about -3.0 – +1.0 m-1 (dpt)
• Focusing Screen Fixed, Precision Matte
• Mirror Quick-return type
• Provide depth of field preview

Autofocus

• Type of image-registration, phase detection TTL 2
• Nine cross-type AF points AF points (f/2.8 at the center AF point detects cross-type AF)
• Focusing brightness range EV-0.5-18 (23 ° C in, ISO 100)
• AF operates One-Shot AF, AI Servo AF, AI Focus AF
• Continuous built-in flash AF assist lamp flashes by

Exposure Control

• Metering modes 63-zone TTL full aperture metering
• Evaluative metering (linkable to any AF point)
• Partial metering (approx. 9% of viewfinder at center)
• Spot metering (approximately 4% of viewfinder at center)
• Center-weighted average metering
• Metering range EV 1 – 20 (23 ℃, ISO 100)
• Exposure Control Program AE (Auto Intelligent Scene, Flash Off, Creative Auto, Portrait, Landscape, Close-up, Sports, Night Portrait,
• Night shooting without a tripod, HDR backlight compensation, Program), shutter-priority AE, Aperture

Priority AE, Manual Exposure
• ISO sensitivity (Recommended Exposure Index) Basic Zone modes: ISO 100 – 3200 range is assigned automatically by
• * Portrait: ISO 100, shooting without a tripod at night: ISO 100 – 12800 automatically sets the
• Creative Zone modes: ISO 100 – 12800 in the range specified in the manual (1 stop increments), ISO 100 – 6400 range, automatically assigned,
• ISO sensitivity up to ISO can be set automatically or ‘H’ (ISO 25600 equivalent) to the ISO extension
• Manual Exposure Compensation 1/3 or 1/2 stop increments ± 5 stops
• AEB: 1/3 or 1/2 stop increments ± 2 stops (in conjunction with manual exposure compensation possible)
• AE Lock Automatic: When focus is achieved with evaluative metering applies in One-Shot AF mode
• Manual: AE lock button and use the

Shutter

• Format electronically controlled focal-plane shutter
• Shutter Speed 1/4000 seconds to 1/60 sec (Scene Intelligent Auto mode), 1/200 sec X – Sync.
• * If you use wide-angle lens, a shutter speed of 1/60 sec or less can be. 1/4000 to 30 seconds, bulb
• (Total shutter speed range. Shutter

speed range varies by shooting mode.)

Flash

• Built-in Flash Auto pop-up flash
• Guide No.: About 13/43 (ISO 100, m / ft)
• Flash Range: 17mm lens angle of about
• Charging time about 3 seconds.
• Provides wireless master unit
• EX-series Speedlite external flash (the camera flash functions can be set in).
• Flash metering E-TTL II auto flash
• Flash Exposure 1.3 or 1.2 stop increments ± 2 stops in
• FE lock available
• No PC terminal

Drive System

• Drive mode, every shot, continuous shooting, 10 seconds or 2-second delay self-timer, continuous shooting 10-second delay
• Continuous shooting speed up to about 5 frames / sec.
• Continuous shooting JPEG Large / Fine: Approx 22 (30) each
• RAW: approximately six (6) every
• RAW + JPEG Large / Fine: Approx 3 (3) every
• * Figures with 8GB card Canon testing standards (ISO 100, ‘Standard’ Picture Style) is based.
• * The figures in parentheses UHS-I compatible with the 8GB card is based on Canon testing standards.

LCD Monitor

• Type TFT color LCD monitor
• Monitor size and dots wide, 7.7cm (3.0 inch) (3:02), approximately 1.04 million dots
• Angle can be adjusted
• Adjust the brightness manually (step 7)
• 25 language interface languages
• Capacitive sensing touch screen technology
• Feature can be displayed

Playback

• Image Display Format

Single, Single image + information (basic information, the shooting information, histogram), four each index, every index of 9, the image can be rotated
• Approximately zoom 1.5x – 10x

Live View shooting

• Set Aspect Ratio 3:2, 4:3, 16:9, 1:1
• Hybrid CMOS AF focusing system * (+ tracking, FlexiZone-Multi, FlexiZone-Single), phase difference detection method (quick mode)
• Manual focus (approximately 5x / 10x magnification possible)
• * Focusing brightness range: EV 1-18 (23 ℃ in, ISO 100)
• Continuous AF can
• Can touch the shutter
• Real-time image sensor Metering mode Metering
• Evaluative metering (315 segments), partial metering (approximately 8.8% of the Live View screen), spot metering (approximately 2.8% of the Live View screen), Center-weighted average
• Metering range EV 0 – 20 (23 ℃, ISO 100)
• Display two kinds of lattice

Video recording

•
• MPEG-4 AVC/H.264 video compression
• Variable (average) bitrate
• Linear PCM audio recording format
• MOV video recording format
• Record the size and
• Frame Rate 1920×1080 (Full HD): 30p/25p/24p
• 1280×720 (HD): 60p/50p
• 640×480 (SD): 30p/25p
• * 30p: 29.97 fps, 25p: 25.00 fps, 24p: 23.976 fps, 60p: 59.94 fps, 50p: 50.00 fps
• File size 1920×1080 (30p/25p/24p): approximately 330 MB / minute
• 1280×720 (60p/50p): approximately 330 MB / minute
• 640×480 (30p/25p): Approximately 82.5 MB / minute
• Hybrid CMOS AF focusing system * (+ tracking, FlexiZone-Multi, FlexiZone-Single)
• Manual focus (approximately 5x / 10x magnification possible)
• * Focusing brightness range: EV 1-18 (23 ℃ in, ISO 100)
• Evaluative metering with image sensor Metering mode and center-weighted pyeonggyuncheukgwang
• * Set the focusing mode automatically, depending on
• Is Servo AF
• Metering range EV 0 – 20 (23 ℃, ISO 100)
• Exposure Control Program AE and Manual Exposure for Video
• Exposure Compensation 1.3 stop increments ± 3 stops (stop pictures: ± 5 stops).
• ISO sensitivity
• (Recommended Exposure Index) Auto exposure shot: ISO 100 – 6400 within the scope of the automatic setting manual exposure, ISO 100 – 6400 within the auto / manual settings,
• H (ISO 12800 equivalent), expandable to
• Video Snapshot 2 seconds / 4 seconds / 8 seconds can be set
• Built-in Stereo Microphone Recording
• Provides an external stereo microphone jack
• Adjustable recording level, wind filter, providing
• Attenuator provides
• Display two kinds of lattice
• Flashing warning highlights overexposed highlight areas
• How a single image, image display, image 100 sheets of 10 hawk jump, jump a CAT scan, folder, jump, jump video, still images, jump, jump grade
• Images can be rotated
• Provided ratings
• Videos can be played (LCD monitors, video / audio output, HDMI

OUT)
• Built-in Speaker
• Images can be protected
• All images slide show, date, folder-, video, still images or five kinds of transitions can be selected rating
• Background music for slideshows and video playback can be selected
• Image processing
• Coarse filter effects, monochrome, soft focus, fisheye lens effect, painting effects, color effects, and toy camera effects and miniature effects
• Can be resized

Direct Printing

• Compatible with PictBridge-compatible printer, the printer
• Printable images JPEG and RAW images
• Compatible with DPOF version 1.1 of the print command

User Settings

• 8 kinds of user-defined functions
• My menu can be registered
• Copyright information can be entered and stored

Interface

• Audio / Video output /
• Digital terminal analog video (NTSC / PAL

selectable) / stereo audio output
• PC communication and direct printing (Hi-Speed USB), GPS Receiver GP-E2 connection
• HDMI mini OUT terminal C-type (resolution, auto-switching), CEC-compatible
• The external microphone input terminal
• 3.5mm diameter stereo mini-jack
• Remote Switch RS-60E3 Remote Control for Terminals
• Remote Controller RC-6 Wireless Remote Control compatible
• Eye-Fi card can be used

Power

• Battery Battery Pack LP-E8 (1 reviews)
• * AC power via AC Adapter Kit ACK-E8 can be used.
• * With Battery Grip BG-E8 AA-size when attaching / LR6 batteries can be used.

Battery Life

• (CIPA test standards basis)
• Viewfinder when shooting: 23 ℃ approximately 440 sheets, 0 ℃ approximately 400 sheets
• Live View shooting: 23 ℃ approximately 180 shots, 0 ℃ approximately 150 sheets
• Video recording time approximately 1 hour and 40 minutes at 23 ℃
• About 1 hour and 20 minutes at 0 ℃
• (Fully charged Battery Pack LP-E8 is used)

Size and Weight

• Dimensions (W x H x D) 133.1 x 99.8 x 78.8 mm approx.
• Weighs about 575 g (CIPA guidelines), approximately 520 g (body only)
• Operating Environment
• Operating temperature range 0 ℃ ~ 40 ℃
• Operating Humidity 85% or less
• Battery Pack LP-E8
• Type of rechargeable lithium-ion battery
• Rated voltage 7.2 V DC
• 1120 mAh battery capacity
• Operating temperature range when charging: 6 ℃ ~ 40 ℃
• Shooting: 0 ℃ ~ 40 ℃
• Operating Humidity 85% or less
• Dimensions (W x H x D) Approx 37.1 x 15.4 x 55.2mm
• Weight about 52g
• Battery Charger LC-E8
• Compatible Battery Battery Pack LP-E8
• Charging time Approximately 2 hours (23 ° C in a)
• Rated input / output rated input: 100 – 240 V AC (50/60 Hz)
• Rated output: 8.4 V DC / 720mA
• Operating temperature range 6 ° C ~ 40 ° C
• Operating Humidity 85% or less
• Dimensions (W x H x D) Approx 69 x 28 x 87.5mm

• Weight about 82
• Battery Charger LC-E8E
• Compatible Battery Battery Pack LP-E8
• Charging time Approximately 2 hours (23 ℃ in a)
• Rated input / output rated input: 100 – 240 V AC (50/60 Hz)
• Rated output: 8.4 V DC / 720mA
• Operating Temperature Range 6 ℃ – 40 ℃
• Operating Humidity 85% or less
• Dimensions (W x H x D) Approx 69 x 28 x 87.5mm
• Weight about 82g

Preis und Verfügbarkeit sollten auch bald folgen...
